Description
| Name | Part Number |
|---|---|
| WABCO | WAB-153101501 |
| Knorr-Bremse | KB-ADB153101501 |
| Meritor | MER-101501 |
| SAF-Holland | SAF-153101501 |
| BPW | BPW-ADB-101501 |
| Haldex | HLDX-153101501 |
| Attribute | Value |
|---|---|
| Material | High Carbon Cast Iron |
| Manufacturing Process | CNC Machined & Balanced |
| Outer Diameter | 430 mm |
| Inner Diameter | OEM Standard |
| Overall Thickness | 45 mm |
| Minimum Thickness | 37 mm |
| Bolt Hole Configuration | 10 Holes |
| Bolt Circle Diameter (BCD) | OEM Specification |
| Mounting Type | Hub Mounted |
| Surface Finish | Ground & Precision Finished |
| Heat Treatment | Yes |
| Ventilation Type | Internal Ventilated |
| Cooling Design | Radial Vent Channels |
| Corrosion Protection | Anti-rust Coating |
| Balancing | Dynamically Balanced |
| Application Type | Air Disc Brake System |
| Vehicle Type | Heavy Commercial Vehicles |
| Operating Temperature Range | High Temperature Resistant |
| Weight | 48 LB |
