Description
| Name | Part Number |
|---|---|
| Parker | 146912D |
| Eaton | 146912 |
| Weatherhead | 912D |
| Gates | G146912 |
| Attribute | Value |
|---|---|
| Design Type | 90° Elbow |
| Nominal Size | 3/4 Inch |
| Thread Size | 3/4″ NPT |
| Thread Gender | Male |
| Connection Type | Compression / DOT Push-to-Connect |
| Standard | DOT Approved |
| Body Material | High-Strength Brass |
| Seal Material | Nitrile Rubber (NBR) |
| Finish / Coating | Corrosion-Resistant / Anti-Oxidation |
| Working Pressure | Up to 200 PSI |
| Burst Pressure | Up to 800 PSI |
| Operating Temperature Range | -40°F to +250°F (-40°C to +121°C) |
| Vibration Resistance | High (Heavy-duty applications) |
| Flow Capacity | High-flow design for larger air volume |
| Leak Protection | Precision sealing for leak-proof performance |
| Installation Type | Threaded + Compression / Push-In |
| Reusability | Yes (Serviceable and reusable) |
| Compatibility | SAE J844 / SAE J1131 Tubing |
| Standards Compliance | DOT FMVSS 571.106 |
| Application Type | Air Brake & Pneumatic Systems |
| Vehicle Compatibility | Heavy-Duty Trucks, Trailers, Buses |
| Environment Resistance | Resistant to oil, moisture, road salts, and debris |
| Orientation Flexibility | Ideal for right-angle installations |
| Color / Appearance | Brass Finish |
| Packaging Type | Individual / Bulk |
| Weight | 0.45 LB |
