Description
| Name | Part Number |
|---|---|
| Parker | ME-6-8 |
| Tectran | 0608-ME |
| Phillips | ME0608 |
| Velvac | 032310 |
| World American | WA01-6275 |
| Attribute | Value |
|---|---|
| Product Type | Pneumatic Brass Fitting |
| Fitting Style | Male Elbow |
| Configuration | Elbow Connector |
| Tube Outer Diameter | 3/8 Inch |
| Male Thread Size | 1/2 Inch |
| Thread Type | Male NPT |
| Body Material | High-Grade Brass |
| Seal Type | Thread Seal Design |
| Operating Media | Compressed Air |
| Working Pressure Range | Up to 150 PSI |
| Operating Temperature Range | -40°F to 200°F |
| Corrosion Resistance | Excellent |
| Vibration Resistance | High |
| Leak Protection | Leak-Resistant Construction |
| Installation Type | Threaded Compression Connection |
| Flow Direction | Angled Flow Configuration |
| Reusable | Yes |
| Application Type | Pneumatic & Air Brake Systems |
| Compatible Tubing | Copper, Nylon & Polyurethane Tubing |
| Industrial Standards | DOT Compatible |
| Finish | Natural Brass Finish |
| Maintenance Requirement | Low Maintenance |
| Weight | 0.16 LB |
