Description
Additional Specifications
Instantaneous maximum current: 600A </= 1s
Rated contact voltage: up to 110 Volts DC
Insulation resistance: >/= 100 MegOhm
Dielectric withstand voltage: 1500 VAC, 1 min, no breakdown
Contact voltage drop: </= 80mV @ 100A
Electrical life: >/= 500,000 cycles
Mechanical life:>/= 300,000 cycles
M8 terminal torque: </= 8.5 N-m
Ingress: IP65
Operating temperature: -25 degC to 55 degC
Dimensions
Weight: 24.6oz / 696g
Height: 3.68″ / 93mm
Width: 2.65″ / 68mm
Width of Mounting Bracket: 3.47″ / 88mm
Depth: 2.9″ / 74mm
Mounting: 2.50″ / 63.5mm on center
Mounting Hardware: 1/4″ or M6
Load studs are compatible with any of our 4 AWG, 2-1 AWG, 1/0 AWG, and 2/0 AWG Eyelets having a 5/16″ hole.
Coil studs are compatible with any of our Ring or Spade Terminals having a 10 hole.
