Description
| Attribute | Value |
| Type | Air Compressor – 318cc |
| Displacement | 318 cc |
| Operating Speed | 3000 RPM |
| Cylinder Type | Single Cylinder |
| Piston Diameter | 3.35 in |
| Piston Stroke | 2.20 in |
| Port Thread Size | M27 x 2, M18 x 1.5, M10 x 1.0 |
| Air Flow | 18.7 CFM |
| Temperature Range | -30°C to +90°C |
| Dimensions | 297.6 x 151.1 x 310.8 mm |
| Weight | 43 lb |
| Engine Compatibility | Cummins ISX / ISX15 |
| Application | Heavy-duty truck air brake systems |
| Material | Heavy-duty cast metal |
| Condition | New aftermarket replacement |
| Brand | Part Number |
| CUMMINS | 3687343 |
| CUMMINS | 3104216 |
| HALDEX | 9111530190 |
| BENDIX | 9111530190 |
| WABCO | 9111530190 |
