Description
Specifications
Dimensions – See drawing above in photos
Maximum Amperage: 200A
Maximum Voltage: 32VDC
Stud Size for Cable Attachments: M8 (5/16″ eyelets)
Recommended Screw Torque: 27 in-lb
Recommended Stud Torque: 120 in-lb
Meets the following regulatory specifications:
CE
IP66 Ingress Protection
ISO 8846 Marine Certified
SAE J1171 Marine Certified
As with all Stainless Steel hardware, we recommend the use of anti-seize when assembling to prevent galling.
