Description
Bosch 0445117023 is a Genuine Bosch OEM common-rail fuel injector (CRI3-20 piezo) for the 2011-2014 Ford 6.7L Powerstroke Super Duty and 2015-2016 Cab-Chassis. Bosch is the OE supplier for the 6.7L Powerstroke high-pressure common rail system, and this piezo-electric injector is built to factory atomization specs at the extreme rail pressures the 6.7L runs. Sold individually — hold-down bolt and high-pressure line are not included.
Signs You Need a New Fuel Injector
- Rough idle or cylinder misfire under load
- Excessive white or black exhaust smoke
- Hard start or extended cranking
- Power loss, hesitation, or knock during acceleration
- Excessive return-fuel volume on injector balance test
Specifications
| Manufacturer | Bosch |
|---|---|
| Part Number | 0445117023 |
| Part Type | Fuel Injector |
| Injector Type | CRI3-20 Piezo Common Rail |
| Condition | New OEM |
| Engine Compatibility | Ford 6.7L Powerstroke V8 Diesel |
| Years | 2011-2014 Super Duty; 2015-2016 Cab-Chassis |
| Includes | Injector only — hold-down bolt and HP line sold separately |
Cross References
This part replaces or is equivalent to the following part numbers:
- Bosch: 0445117024, 0986435415
- Ford: BC3Z-9H529-A, BC3Z-9H529-B, BC3Z-9H529-C, BC3Z-9H529-D, BC3Z-9H529-E, BC3Z-9H529-F, BC3Q-9K546-AB, BC3Q-9K546-AD
- Motorcraft: CN-5022, CN-5023, CN-6025, CN-6026
- Standard Motor Products: FJ1221, FJ1222
- GB Remanufacturing: 722-509, 722-510
Cylinder Position Reference
The Ford 6.7L Powerstroke uses position-specific injector calibration codes:
- Cylinders 1, 2, 7, 8: Ford BC3Z-9H529-A / -C / -E
- Cylinders 3, 4, 5, 6: Ford BC3Z-9H529-B / -D / -F
Confirm the required cylinder position before ordering.
Applications
This fuel injector fits Ford 6.7L Powerstroke V8 diesel engines in:
- 2011-2014 Ford F-250 / F-350 / F-450 / F-550 Super Duty 6.7L Powerstroke
- 2015-2016 Ford F-350 / F-450 / F-550 Cab-Chassis 6.7L Powerstroke
Verify your engine serial number and configuration before ordering to confirm fitment.
