Description
The Dexter® DX1000 Model Electric Over Hydraulic Brake Actuator (K71-650-00) delivers reliable 1,000 psi maximum pressure output for trailers equipped with hydraulic drum brakes. This actuator provides proportional braking response based on input from your electric brake controller.
Key Features
- Model: DX1000 – 1,000 psi for drum brake applications
- Part Number: K71-650-00
- Power: 12-volt DC operation with 4-wire connection
- Fluid: Uses DOT 3 or DOT 4 brake fluid
- Battery Requirement: Minimum 9 amp/hour breakaway battery recommended
- Construction: Sealed, anodized aluminum housing for corrosion resistance and heat dissipation
Specifications
- Pressure Output: 1,000 psi maximum
- Dimensions: Approximately 11.38″ long x 6″ wide x 7″ high
- Application: Suitable for 1-3 axles with hydraulic drum brakes
Fitment Note
Verify compatibility with your trailer’s brake system, controller, and electrical setup before ordering. Confirm all measurements, wiring requirements, and specifications match your application. Contact Southwest Wheel for assistance if needed.
For related products, browse our selection of Dexter® Axle components and trailer parts and axles.
Electric/hydraulic brake actuator for axles equipped with drum brakes.
| Dx Part No | Quantity | Description |
| 071-650-00 | 1 | Electric/Hydraulic Brake Actuator – 1000 |
| LIT-608-00 | 1 | E/H Brake Actuator Service Manual |
DX Series Features
- All stainless steel fasteners for superior corrosion resistance
- sealed to protect the circuit board from water and protection against the elements
- Finned housing design helps dissipate heat more efficiently for long-lasting durability
- Incorporates enhanced wiring protection to prevent possible damage to the unit if wire improperly
- Solid state electronics for improved performance and compatibility with most aftermarket and OEM integrated electric brake controllers on the market
- Large brake fluid reservoir and self-priming pump reduce the time required for brake bleeding while preventing the system from running dry during the process
- Large reservoir accommodated brake life on single tandem or triple axle applications
- Two-year limit warranty
- ISO 9001:2015 Certified Production Environment
