Description
Specifications
Dimensions: See drawing above in photos
Stud: M8 Stainless Steel
Maximum Amperage: 300A*
Maximum Voltage: 32VDC*
Ignition Protected: per SAE J1117*
Ingress Protection: IP66*
Stud Size for Fuse: M8 (5/16″ eyelets)
Recommended Stud Torque: 106 in-lb (12 N•m)
*When using Marine Rated Battery Fuses (MRBF)
As with all Stainless Steel hardware, we recommend the use of anti-seize when assembling to prevent galling.
