Description
Fits Dexter Torflex 9 removable spindle system.
| Dx Part No | Quantity | Description |
| 002-287-22 | 1 | Spindle 9 |
| 005-023-00 | 1 | Washer, “D” |
| 005-162-00 | 1 | Washer, Lock |
| 006-190-00 | 1 | Nut, Retainer |
| 006-191-00 | 1 | Nut, Hex |
| 007-288-00 | 1 | Screw, Hex |
| 088-008-00 | 1 | Grease Packet |
| 059-897-00 | 1 | Instruction Sheet |
FAQs
Can I add this feature to my existing axle?
- No, if your axle is not equipped with the removable spindle option, it cannot be added.
Do i have to replace the hubs?
- Only if they have been damaged, but you should replace bearing cones, cups and seals.
Can the arm assembly be replaced?
- No, it is welded in place.
Can i change to a large size spindle?
- No, each size spindle is made for a specific axle.
Can i change the axle starting angle?
- No, the angle is not adjustable.
Will my old hubs fit my replacement spindle?
- Yes, the new spindles are sized for the axle capacity.
Do i need special tools to change the spindle?
- No, standard hand tools are all that is required.
I can’t get the spindle out of the hole.
- Follow the Installation/Removal procedure instructions. You may need to drive the wedge in deeper. If rusted, spray with penetrating oil.
The threads are damaged in the arm, can i repair them?
- Yes, try cleaning up the threads with a 1/2″ -20 thread tapping die.
How long will it take to replace one spindle?
- Approximately 15 minuted after hub or hub, drum & brake removal.
