Description
Fleetguard FK22005 is the fuel filter service kit for the International Navistar MaxxForce 7 6.4L V8 turbodiesel (2011–2018), replacing International 1884207C91 / 1884207C92, Baldwin PF9914 KIT, and Wix WF10066. Kit contains both spin-on fuel filters used on the MaxxForce 7: the primary fuel/water separator and the secondary fuel filter, both built on Fleetguard NanoNet synthetic media. The two filters are not sold individually as part of this kit.
Kit Includes
- Primary fuel/water separator — Fleetguard FS20046 (qty 1)
- Secondary fuel filter — Fleetguard FS20045 (qty 1)
Specifications
| Manufacturer | Fleetguard (Cummins Filtration) |
|---|---|
| Part Number | FK22005 |
| Replaces (OEM) | International 1884207C91 / 1884207C92 |
| Part Type | Fuel Filter Kit (Primary FWS + Secondary Fuel) |
| Engine Compatibility | International / Navistar MaxxForce 7 (6.4L V8 turbodiesel) |
| Filter Media | Fleetguard NanoNet |
| Components | FS20046 (primary, fuel/water separator) + FS20045 (secondary) |
Cross References
This fuel filter kit replaces or is equivalent to the following part numbers:
- International (Navistar): 1884207C91, 1884207C92
- Fleetguard: FK22005
- Baldwin: PF9914 KIT, PF9914KIT
- Wix: WF10066
- Donaldson: P551625
- Luber-finer: L7662FK
- Premium Guard: PFF33286
Applications
This fuel filter kit fits the International / Navistar MaxxForce 7 6.4L V8 turbodiesel found in:
- International TerraStar (2011–2014)
- International 4300 (2011–2018, MaxxForce 7 option)
- International DuraStar (2011–2018, MaxxForce 7 option)
- International CityStar / WorkStar with MaxxForce 7
Service both filters as a set at the OEM-recommended interval. Primary FWS without the secondary — or vice versa — defeats the layered filtration the MaxxForce 7 fuel system was designed around.
