Description
Spin-on fuel/water separator for New Holland Genesis-series 8670A, 8770A, 8870A, and 8970A row-crop tractors. Replaces New Holland 87840136 (supersedes 87803210, 84446332, 7840136) and crosses to Baldwin BF1223-O, Donaldson P551852, Mann WK1142, and Hengst H7060WK10. 1-14 UNF spin-on thread; outside-in flow.
Specifications
| Manufacturer | Fleetguard |
|---|---|
| Part Number | FS19687 |
| Part Type | Fuel/Water Separator (Spin-On) |
| Engine Compatibility | New Holland Genesis 8670A / 8770A / 8870A / 8970A tractors |
| Thread Size | 1-14 UNF (1.0 in, 14 TPI) |
| Largest OD | 4.35 in (110.5 mm) |
| Overall Height | 5.18 in (131.5 mm) |
| Gasket OD / ID | 3.58 in / 3.15 in |
| Flow Direction | Outside-in |
Cross References
This part replaces or is equivalent to the following part numbers:
- New Holland / CNH: 87840136, 87803210, 84446332, 7840136, 47961126
- Baldwin: BF1223-O
- Donaldson: P551852
- Mann: WK1142
- Hengst: H7060WK10
- HiFi: SN906010
- Racor: R60T
- Also known as: 32925218
Applications
This fuel/water separator fits the following tractors:
- New Holland Genesis 8670A / 8770A / 8870A / 8970A (1996-2002)
Verify your engine serial number and configuration before ordering to confirm fitment.
