Description
Fleetguard LF3646 is a small spin-on full-flow lube oil filter (3.12 in OD x 3.08 in tall, M20x1.5 mounting thread) used on John Deere compact agricultural diesels (4045 / utility tractor / sub-compact platforms), Bomag compactors, CNH compact equipment, Ingersoll-Rand industrial diesels, and Kubota/Yanmar small-engine industrial packages. 11 PSI bypass valve, 30 micron efficiency.
Specifications
| Manufacturer | Fleetguard |
|---|---|
| Part Number | LF3646 |
| Part Type | Spin-On Full-Flow Lube Oil Filter |
| Outer Diameter | 3.12 in (79.25 mm) |
| Overall Height | 3.08 in (78.23 mm) |
| Thread | M20 x 1.5-6H |
| Bypass Valve Setting | 11 PSI (76 kPa) |
| Efficiency | 30 micron nominal |
Cross References
This part replaces or is equivalent to the following part numbers:
- John Deere: M806419
- CNH (Case / New Holland): S19100650011
- Bomag: 5740096
- Donaldson: P550162
- Baldwin: B7216
- Wix: 51334
- Luber-Finer: PH3942
- Champion Laboratories: PH2805, PH2808, PH7010
- AMSOIL: EAO20
- Delphi: FX1000
- Crosland: 672
- Big A: 92389
- Carquest: 85334, 85389
- Canadian Tire: 27-5506-6, 27-5511-2
- Casite: CF3593
- Clean: DO1869
- Champ: PH2808
- Dorcy: 21-8065
- Emgo: 10-82200
Applications
This oil filter fits the following engines and equipment:
- John Deere compact / utility tractor diesels using the M806419 lube filter (sub-compact and compact tractor families)
- CNH (Case / New Holland) compact construction and ag equipment using S19100650011
- Bomag compactors and rollers using 5740096
- Ingersoll-Rand industrial / construction equipment
- Kubota and Yanmar small industrial diesel packages cross-referenced to this filter platform
Verify your engine’s lube filter mounting (M20 x 1.5 thread, 3.12 in OD) and gasket OD before ordering. Always pre-fill spin-on oil filters with engine oil and apply a thin film of oil to the gasket before installation.
