Description
The Graco XD80 Diesel Fuel Hose Reel (Part 24R572) is built for professionals who need safe, reliable fuel dispensing. Featuring a direct-drive 115 VAC electric motor, it eliminates exposed chains and gears, reducing maintenance while improving operator safety. This makes it the right choice for technicians in fleet maintenance, mining, public works, and agriculture.
Designed for demanding environments, the XD80 reel handles up to 50 feet of 2-inch hose capacity. Its heavy-duty welded spool shields the drive system from harsh conditions, extending equipment life. In addition, the welded box-style frame offers superior strength compared to bolted frames that can loosen over time. Each component is individually powder-coated for long-lasting corrosion resistance, making this reel ideal for both indoor and outdoor use.
The XD80 reel also provides easy installation and system flexibility. You can quickly adjust inlet and motor direction, giving you left or right-hand flow orientation. With a maximum working pressure of 600 PSI and wide temperature tolerance, the Graco XD80 Diesel Fuel Hose Reel (24R572) ensures safe, efficient, and long-lasting fueling performance across many industries.
Features & Specifications
- Part Number: 24R572
- 2 in. inlet/outlet with NPT female threads
- 50 ft. (15 m) hose capacity
- 115 VAC direct-drive electric motor
- Maximum working pressure: 600 PSI (41 bar)
- Operating temperature range: -40°F to 140°F
- Rated power: 0.4 HP | Speed: 500 RPM
- Heavy-duty welded spool and box frame construction
- Individually powder-coated components for corrosion resistance
- Dry weight: 179 lbs (81 kg)
- Recommended fluid: Diesel fuel
