Description
*As with all Stainless Steel hardware, we recommend the use of anti-seize when assembling to prevent galling.
Dimensions are as follows:
Base – 4.77″ x 1.88″ / 121mm x 47.8mm
Base to Top of Studs – 2.84″ / 72.2mm
Base to Top of Cover – 3.08″ / 78.3mm
Length of Cover – 7.375″ / 187.3mm
Hardware to Mount – 1/4″
Max Fuse Rating @ 12VDC – 750A
Max DC Volts – 48VDC
Maximum Current, continuous – 495A
Max Current for 60sec – 825A
