Description
The PAI 641292 is an aftermarket front-sump oil pan kit for Detroit Diesel DD15 engines, supplied with all gaskets, hardware, fittings, and drain plug components needed for installation. It replaces Detroit Diesel A4720102313 with a 47-quart capacity, plastic pan body, wet-sump configuration, and 18 mounting points. PAI sources kit components to OE specifications (642293, A4720102813 pan body) for direct service replacement.
Specifications
| Manufacturer | PAI Industries |
|---|---|
| Part Number | 641292 |
| Part Type | Oil Pan Assembly Kit |
| Engine Compatibility | Detroit Diesel DD15 |
| Sump Location | Front |
| Sump Style | Wet |
| Capacity | 47 quarts |
| Material | Plastic |
| Color / Finish | Black |
| Mounting Holes | 18 |
| Drain Plug Thread | M27 x 2.0 |
| Total Ports | 2 |
| Pan Dimensions (L x W x H) | 43.75 x 16.18 x 15.00 in |
| Warranty | 2 years (PAI) |
Kit Includes
- Oil pan body — PAI 641293 (OEM Detroit Diesel A4720102813)
- Oil pan fitting — PAI 640146 (OEM Detroit Diesel A4729970071)
- Washer — PAI 842033
- Pan gasket — PAI 631359 (OEM Detroit Diesel A4720140322)
- Screw assembly — PAI 640045 (OEM Detroit Diesel A4720140583) (qty 18)
- Slotted nut — PAI 640110 (OEM Detroit Diesel A4729900155) (qty 2)
- O-ring — PAI GGA-2909 (OEM Detroit Diesel 56AX596) (qty 2)
- Threaded insert — PAI 640111 (OEM Detroit Diesel A4729900551) (qty 2)
- Drain plug kit — PAI 640132 (OEM Detroit Diesel A4729900217) (qty 2; each kit includes drain plug 640129/A0019908917 and copper washer 640081/N007603027100)
- Oil pan installation guide — PAI 1283
Cross References
This oil pan kit replaces or is equivalent to the following part numbers:
- Detroit Diesel: A4720102313
Applications
This oil pan kit fits the following engines:
- Detroit Diesel DD15 14.8L (2007+)
Representative vehicles using this engine:
- Freightliner Cascadia, Coronado, Columbia (2007+)
- Western Star 4900, 5700XE (2008+)
Verify your engine serial number and front-sump configuration before ordering to confirm fitment.
