Description
Reelcraft – L 4545 123 7Q – Spring Rewind Cord Reel
Reelcraft’s Series L 4000 light cord reel includes an incandescent lamp with a single receptacle tool tap. The reel is supplied with a 4-5 foot pigtail that includes a NEMA L5-15P inlet twist lock plug. For indoor, non-weather tight applications only. *UL/CSA approved*
- Reinforced steel – The robotically welded steel base offers maximum strength and consistent quality.
- Heavy-duty collector ring – A robust collector ring assures maximum conductivity current flow.
- Long-life drive spring – Declutching arbor virtually eliminates the possibility of spring damage due to reverse winding. Only the highest quality spring steel is used and conditioned to ensure there are no imperfections offering maximum service life.
- Quality finish and corrosion resistant – Individually powder coated components offer the maximum protection from premature corrosion.
- Made in USA
Specifications
- Volts:125
- Cord/Cable Length:45′
- Cord/Cable Included:Yes
- Cord Ending:Quad Outlet Box
- Conductors:3
Dimensions
| A | 12.875″ |
| B | 12.625″ |
| C | 8″ |
| D | 2.5″ |
| E | 9.375″ |
| F | 1.75″ |
