Description
Grote SuperNova 53552 4″ round 10-diode LED stop/tail/turn lamp in red, grommet-mount with AMP plug. Hermetic lens-to-housing seal and pattern-emitting reflector design. Direct functional equivalent to Truck-Lite Super 44 44302R, Grote 532523 (incandescent supersession), and other 4″ round red stop/tail/turn lamps.
Specifications
| Manufacturer | Grote |
|---|---|
| Part Number | 53552 |
| Part Type | Stop / Tail / Turn Lamp (LED) |
| Series | SuperNova 4″ Pattern |
| Lens Color | Red |
| Diameter | 4 in |
| Diode Count | 10 |
| Mount | Grommet (mating grommet sold separately) |
| Connection | AMP-style 3-pin connector |
| Voltage | 12 V |
Cross References
This lamp replaces or is functionally equivalent to the following part numbers:
- Grote: 53552, 53252 (related 4″ red SuperNova), 532523, GR532523, GR53312
- Truck-Lite: 44302R, 44202R, 44882R, TL44302R, TL44202R, TL44882R, MSTL44302R, L44202R, 4464
- Also known as: 202R, 302R, 7071183, 8413-44302R, 841344302R, VS4464
Applications
Standard 4″ round red stop/tail/turn lamp used across heavy-duty Class 7–8 tractors, trailers, and vocational chassis fitted with 4″ grommet-mount tail-lamp positions, including:
- Freightliner, Kenworth, Peterbilt, Volvo, Mack, Western Star, International tractor cabs and sleepers
- Standard van, flatbed, dump, tank, and lowboy trailers (Great Dane, Wabash, Utility, Strick, Vanguard)
- Vocational chassis (refuse, fire, dump, mixer)
Verify the existing tail-lamp pocket dimension (4″ round) and connector style before ordering. Use a Grote 91400 (or equivalent) grommet and 67000-style pigtail if not present.
