Description
OTR PTL3009A 2-inch round amber 9-LED marker/clearance lamp on a Power Products LLC platform — direct replacement for the Truck-Lite 3050A Signal-Stat (6-diode), with a higher-density 9-diode array in the same 2″ round footprint. Polycarbonate construction, 12V / 0.09A, grommet-mount housing, FMVSS 108 P2 rated.
Specifications
| Manufacturer | OTR (Power Products LLC) |
|---|---|
| Part Number | PTL3009A |
| Function | Marker / Clearance Light |
| Lens Color | Amber |
| Lens Shape | Round, 2″ diameter |
| Light Source | LED, 9 diodes |
| Voltage / Current | 12V / 0.09A |
| Mounting | Grommet mount (standard 2″ round grommet, sold separately) |
| Construction | Polycarbonate lens / housing |
| Compliance | FMVSS P2 |
Cross References
This part replaces or is equivalent to the following part numbers:
- Truck-Lite: 3050A (Signal-Stat 2″ round 6-diode amber LED); 3053A
- Grote: G3003 (Hi Count 2″ round amber LED)
- Maxxima: M09100Y
- Peterson: 165A (2″ round amber LED)
- Optronics: MCL50ABP; MCL55AB
- PrimaTronics: PTL3004A
- Navistar OEM: FLTCM20009A
- Also known as: M34260Y, MCL56AB
Applications
Side-marker and clearance lamp for heavy-duty truck cabs, sleepers, fenders, and trailer header rails — anywhere a 2″ round grommet-mount amber LED marker is required by FMVSS 108. Drop-in upgrade from incandescent 2″ round lamps (Truck-Lite 30200Y, Grote 45823) to LED.
For the red lens version of this lamp, see OTR PTL3009R. Truck-Lite 30080Y high-profile 30-diode is a different (taller) form factor, not a direct cross.
